CTech VanPro Package FT2 Model FT-PRO-2

CTech VanPro Package FT2 Model FT-PRO-2

Maximize your Ford Transit’s potential with the VanPro Package FT2—designed for Ford Transit 150/250/350 medium or high roof models. This complete storage solution includes everything you need for optimal organization and functionality on the go. Built from durable aluminum, the package includes a VanPro Workbench FT-304, MotionGlide Shelving Units, and additional drawer housing to ensure that you’re fully equipped to work and stay organized wherever you are.

Features:

• Two Inch Shelf Adjustment
• Lightweight
• Removable Dividers
• Shelves can adjust vertically

Cabinet Overview

Model/Part	Details
FT-304 Workbench	Quantity: 1 Location: Front Streetside Overall Size: 56"W x 36"H x 14"D Frame Size: 56"W x 36"H x 14"D Note: Cabinet height excludes 2.25" backsplash
FT-300	Quantity: 1 Location: Rear Streetside Overall Size: 56"W x 60"H x 14"D Frame Size: 56"W x 60"H x 14"D
FT-301	Quantity: 1 Location: Rear Curbside Overall Size: 41"W x 60"H x 16"D Frame Size: 41"W x 60"H x 16"D
MG-9 Drawer Unit	Quantity: 2 Mounted in: FT-301 Unit Size: 18"W x 25"H x 14"D Weight: 36 lbs Finish: Tool Cabinet White (Powder Coat & Extrusion)
FT-305 Drawer Housing	Quantity: 1 Location: — Overall Size: 16"W x 32"H x 30"D Frame Size: 16"W x 32"H x 30"D

Cabinet Options

• GasketLoc Countertop - Plastic Laminate (FT-304)
• Clear Anodized Door and Drawer Handles
• Clear Anodized Frame
• Back Panel (where noted)
• Bottom Rail
• Top Panel
• Floor Panel (FT-305)
• Custom Deep Shelves with Dividers (FT-300)
• Transit Profile

Opening Details

Model/Opening	Details
FT-304 - Opening 1	Size: 25.75"W x 17"H Drawers: 3", 3", 5", 5" [Lnr] Slide Type: Medium Duty 12" (x4) Inside Drawer Dim: 21.28"W x 11.671"D Bottom Space: 0.952"
FT-304 - Opening 3	Size: 25.75"W x 17"H Drawers: 4", 5", 7" [Lnr] Slide Type: Medium Duty 12" (x3) Inside Drawer Dim: 21.28"W x 11.671"D Bottom Space: 0.952"
FT-304 - Opening 2	Size: 53"W x 15.5"H EMPTY Additional Option: Delete back panel
FT-300 - Opening 1	Size: 53"W x 40"H EMPTY Adjustable Shelves: 2 (54.758"W x 12"D)
FT-300 - Opening 2	Size: 53"W x 15.5"H EMPTY Fixed Shelf
FT-301 - Opening 1	Size: 38"W x 40"H EMPTY Adjustable Shelf: 1 (39.758"W x 14"D)
FT-301 - Opening 2	Size: 38"W x 15.5"H EMPTY Fixed Shelf
MG-9 Drawer Heights	3", 3", 3", 6", 6"
FT-305 - Single Opening	Size: 13"W x 29"H Drawers: 3", 3", 4", 5", 6", 7" [Lnr] [Sep:4] [STS] Divider Clip Kit: Qty 4 Slide Type: Medium Duty 28" (x6) Inside Drawer Dim: 8.53"W x 27.671"D Bottom Space: 0.952"

Vehicle Fitment

Product Application	Work Van
Vehicle	Ford Transit
Model Year	2014-2025
Wheelbase	148"
Cargo Length	Standard
Cargo Roof Height	Medium, High
Chassis Rear Wheel Configuration	Single Rear Wheel (SRW)
